Ajax Vhfbridge Jeweller — Accessory

Ajax Vhfbridge Jeweller — a module that allows connecting third-party VHF transmitters to the Ajax security system. Original Ajax — with official warranty.

Technical Specifications

• Product Type: Module that allows connecting third-party VHF transmitters to the Ajax security system
• Compatibility: Compatible with Ajax Hub 2, Hub Plus, Hub 2 Plus, and Hub Hybrid
• Communication Protocol: Jeweller (two-way encrypted communication)
• Maximum Communication Range: Up to 1,800 meters in open space
• Power Supply: 100–240 V AC; additionally, a 12 V DC backup battery can be used (not included)
• Backup Battery Support: Supports 12 V batteries up to 7 Ah; provides up to 75 hours of autonomous operation
• Outputs: 8 transistor outputs for connecting third-party VHF transmitters
• Output Types: Configurable as high or low potential; pulse duration adjustable from 1 to 255 seconds
• VHF Transmitter Power Supply: 12 V DC output with a maximum current of 2 A
• Tamper Protection: Yes; detects device removal or displacement
• Operating Temperature Range: −10°C to +40°C
• Humidity: Maximum 75%
• Protection Class: IP50
• Dimensions: 196 × 238 × 100 mm (with enclosure); 145 × 89 × 51 mm (without enclosure)

Order Ajax Vhfbridge Jeweller — delivery throughout Georgia.
