Dream Machine: UniFi Dream Machine Pro Max (UDM-Pro-Max)

UniFi Dream Machine Pro Max (UDM-Pro-Max) — Ubiquiti's most powerful rack-mount (1U) Cloud Gateway: a router, firewall, UniFi network controller, and video surveillance NVR in a single device. Ideal for medium to large offices, hotels, and enterprises requiring high speeds even with security features (IDS/IPS) enabled.

Technical Specifications:

🔹 Brand – Ubiquiti UniFi
🔹 Model – UDM-Pro-Max
🔹 IDS/IPS Throughput – 5 Gbps
🔹 Ports – 8 × 1 GbE RJ45, 1 × 2.5 GbE RJ45 (WAN), 2 × 10G SFP+ (WAN / LAN)
🔹 WAN – Multi-WAN, up to 8 WAN ports, load balancing
🔹 Management – 200+ UniFi devices, 2000+ clients
🔹 Video (UniFi Protect) – Max. 50 HD / 25 2K / 15 4K cameras, 2 × 3.5" HDD slots
🔹 Applications – UniFi Network, Protect, Access, Talk, Connect
🔹 VPN / SD-WAN – WireGuard, OpenVPN, IPsec, L2TP, Teleport, Site Magic
🔹 Routing – OSPF, BGP, LACP, advanced QoS, built-in RADIUS
🔹 Reliability – Shadow Mode (VRRP) — redundancy with a second device, DC backup power (USP-RPS)
🔹 Processor / Memory – Quad-core ARM Cortex-A57 2.0 GHz, 8 GB RAM, 32 GB eMMC + 128 GB SSD
🔹 Display – 1.3" touchscreen
🔹 Power – 100–240V AC, internal 100W; max. consumption 60W
🔹 Format / Size – 1U rack-mount, 442.4 × 43.7 × 285.6 mm, 4.7 kg

✅ Original products, consultation, installation, and network configuration from ITGS.
